ATE 24.0109-0182.1 Brake Disc for Suzuki
USD 71.59 USD
ATE 24.0109-0182.1 Brake Disc for SUZUKIHIGHLIGHTED PART IN DIAGRAM ONLY. Manufacturer: ATE. AP 15113 V. Brake Disc Type solid. Brake Disc Thickness [mm] 9,0. SUZUKI 55611-61M00. SUZUKI 55611-61M20. SUZUKI 55611-61M21.
Specifications
| Hersteller | ATE |
| Herstellernummer | 24.0109-0182.1 |
| EAN | 4006633415651 |
| Produkttyp | Brake Disc |
| Gebr-Nummer(s) | 24.0109-0182.1, 409182 |
| Test Mark | E1 90R-02C0165/0836 |
| Height [mm] | 43,2 |
| Bore Diameter [mm] | 14,0 |
| Brake Disc Type | solid |
| Brake Disc Thickness [mm] | 9,0 |
| Minimum Thickness [mm] | 8,0 |
| Inner Diameter [mm] | 146,6 |
| Outer Diameter [mm] | 259,4 |
| Centering Diameter [mm] | 62,0 |
| Bolt Hole Circle Ø [mm] | 114,3 |
| Surface | Coated |
