ATE 24.0120-0128.1 Brake Disc for SEAT,VW
USD 62.19 USD
ATE 24.0120-0128.1 Brake Disc for SEAT, VWHIGHLIGHTED PART IN DIAGRAM ONLY. Manufacturer: ATE. Brake Disc Thickness [mm] 20,0. SEAT 321 615 301 D. SEAT 6N0 615 301 D.
Specifications
| Hersteller | ATE |
| Herstellernummer | 24.0120-0128.1 |
| EAN | 4006633081016 |
| Produkttyp | Brake Disc |
| Gebr-Nummer(s) | 24.0120-0128.1, 420128 |
| Test Mark | E1 90R-02C0115/0442 |
| Height [mm] | 38,8 |
| Bore Diameter [mm] | 13,8 |
| Brake Disc Type | Vented |
| Brake Disc Thickness [mm] | 20,0 |
| Minimum Thickness [mm] | 18,0 |
| Machining | Alloyed/High-carbon |
| Inner Diameter [mm] | 131,5 |
| Outer Diameter [mm] | 256,0 |
| Centering Diameter [mm] | 65,0 |
| Bolt Hole Circle Ø [mm] | 100,0 |
| Surface | Coated |
| Supplementary Article/Info 2 | with bolts/screws |
| Ursprungsland | Deutschland |
ATE 24.0120-0128.1 Brake Disc for SEAT, VWHIGHLIGHTED PART IN DIAGRAM ONLY. Manufacturer: ATE. Brake Disc Thickness [mm] 20,0. SEAT 321 615 301 D. SEAT 6N0 615 301 D.
