ATE 24.0122-0300.1 Brake Disc for Abarth, Fiat, Mazda
USD 90.33 USD
ATE 24.0122-0300.1 Brake Disc for ABARTH, FIAT, MAZDAHIGHLIGHTED PART IN DIAGRAM ONLY. Manufacturer: ATE. FIAT 6000612391. MAZDA N251-33-251. Brake Disc Thickness [mm] 22,0. We will give you proper part number for needed spare part.
Specifications
| Hersteller | ATE |
| Herstellernummer | 24.0122-0300.1 |
| EAN | 4006633459334 |
| Produkttyp | Brake Disc |
| Gebr-Nummer(s) | 24.0122-0300.1, 422300 |
| Test Mark | E1 90R-02C0115/1014 |
| Height [mm] | 43,9 |
| Bore Diameter [mm] | 13,4 |
| Brake Disc Type | Vented |
| Brake Disc Thickness [mm] | 22,0 |
| Minimum Thickness [mm] | 20,0 |
| Inner Diameter [mm] | 124,5 |
| Outer Diameter [mm] | 280,0 |
| Centering Diameter [mm] | 55,0 |
| Bolt Hole Circle Ø [mm] | 100,0 |
| Surface | Coated |
| Ursprungsland | Deutschland |
ATE 24.0122-0300.1 Brake Disc for ABARTH, FIAT, MAZDAHIGHLIGHTED PART IN DIAGRAM ONLY. Manufacturer: ATE. FIAT 6000612391. MAZDA N251-33-251. Brake Disc Thickness [mm] 22,0. We will give you proper part number for needed spare part.
