ATE 24.0130-0246.1 Brake Disc for LAND ROVER
USD 114.61 USD
ATE 24.0130-0246.1 Brake Disc for LAND ROVERHIGHLIGHTED PART IN DIAGRAM ONLY. Manufacturer: ATE. LAND ROVER LR059122. Brake Disc Thickness [mm] 30,0. Test Mark E1 90R-02C0115/1107. Machining Alloyed/High-carbon.
Specifications
| Hersteller | ATE |
| Herstellernummer | 24.0130-0246.1 |
| EAN | 4006633471572 |
| Produkttyp | Brake Disc |
| Vergleichsnummer | LAND ROVER LR059122 |
| Gebr-Nummer(s) | 24.0130-0246.1, 430246 |
| Test Mark | E1 90R-02C0115/1107 |
| Height [mm] | 52,0 |
| Bore Diameter [mm] | 15,8 |
| Brake Disc Type | Vented |
| Brake Disc Thickness [mm] | 30,0 |
| Minimum Thickness [mm] | 28,0 |
| Machining | Alloyed/High-carbon |
| Inner Diameter [mm] | 144,9 |
| Outer Diameter [mm] | 325,0 |
| Centering Diameter [mm] | 63,5 |
| Bolt Hole Circle Ø [mm] | 108 |
| Surface | Coated |
ATE 24.0130-0246.1 Brake Disc for LAND ROVERHIGHLIGHTED PART IN DIAGRAM ONLY. Manufacturer: ATE. LAND ROVER LR059122. Brake Disc Thickness [mm] 30,0. Test Mark E1 90R-02C0115/1107. Machining Alloyed/High-carbon.
