ATE 24.0134-0103.1 Brake Disc for Audi

USD 194.78 USD

SKU: AIxOVQ8Z

MPN: 24.0134-0103.1

Condition: New

ATE 24.0134-0103.1 Brake Disc for AUDIHIGHLIGHTED PART IN DIAGRAM ONLY. Manufacturer: ATE. TRW DF6216. Brake Disc Thickness [mm] 34,0.

Tags: 0 986 479 748 112,0 14,90 15,3 24.0134-0103.1 24.0134-0103.1, 434103 315 340 356,0 4006633382069 52,4 68,0 ATE Brake Disc coated Deutschland E1 90R-02C0115/1004 High-carbon Vented with bolts/screws

Categories: Brakes & Brake Parts

Specifications

Hersteller	ATE
Herstellernummer	24.0134-0103.1
EAN	4006633382069
Produkttyp	Brake Disc
Gebr-Nummer(s)	24.0134-0103.1, 434103
Test Mark	E1 90R-02C0115/1004
Height [mm]	52,4
Bore Diameter [mm]	15,3
Brake Disc Type	Vented
Brake Disc Thickness [mm]	34,0
Minimum Thickness [mm]	31,5
Machining	High-carbon
Inner Diameter [mm]	149,0
Outer Diameter [mm]	356,0
Centering Diameter [mm]	68,0
Bolt Hole Circle Ø [mm]	112,0
Surface	Coated
Supplementary Article/Info 2	with bolts/screws
Ursprungsland	Deutschland
