For Chevrolet Aveo (04-11), Chevrolet Aveo5 (07-11) Front D&S Rotors
USD 133.45 USD
Model: Aveo, Aveo5, Spark, Spark EV, G3. apf - Rotors. APF - Rotors. Make: Chevrolet, Pontiac. This is a condensed summary. LTZ Hatchback 4-Door. Our support team is located in the U.S. We respond within 24 hours.
Specifications
| Country Of Origin | Imported |
| Manufacturer Part Number | ZDS-RF-328568 |
| Placement On Vehicle | Front, Left, Right |
| Rotor Style | Zinc Drilled & Slotted |
| Fitment Type | Direct Replacement |
| Surface Finish | Zinc Plated |
| Rotor Outside Diameter | 256 MM / 10.079 Inch |
| Rotor Weight | 11.5 LB |
| Misc Holes | 4 Holes |
| Disc Mounting | Floating |
| Surface Type | Smooth |
| Center Hole Diameter | 59.1 MM / 2.327 Inch |
| Item Height | 41.1MM / 1.618 Inch |
| Nominal Thickness | 0.941 Inch |
| Stud/Lug Hole Diameter | 12.6 MM / 0.496 Inch |
| Discard Thickness | 22 MM / 0.866 Inch |
| Mounting Bolt Hole Circle Diameter | 100 MM / 3.937 Inch |
| California Prop 65 Warning | Prop 65 Item |
| Performance Part | Yes |
| Material | Cast Iron |
| OE/OEM Part Number | Contact for details |
| Type | Brake Disc Rotor |
| UPC | 840118382748 |
