For GMC Savana 3500 2007-2020 - Rear Drilled and Slotted Rotors
USD 257.01 USD
Model: Savana 3500. apf - Rotors. APF - Rotors. Slots - Designed to help clear debris and maintain a smoother braking surface. Base Extended Passenger Van 3-Door. Our support team is located in the U.S.
Specifications
| Country Of Origin | Imported |
| Manufacturer Part Number | ZRRO1249 |
| Placement On Vehicle | Rear, Left, Right |
| Rotor Style | Zinc Drilled & Slotted |
| Fitment Type | Direct Replacement |
| Surface Finish | Zinc Plated |
| Rotor Outside Diameter | 330 MM / 12.992 Inch |
| Rotor Weight | 24 LB |
| Misc Holes | 0 Holes |
| Disc Mounting | Floating / DIH |
| Surface Type | Smooth |
| Center Hole Diameter | 117.6 MM / 4.63 Inch |
| Item Height | 85.7MM / 3.374 Inch |
| Nominal Thickness | 1.142 Inch |
| Stud/Lug Hole Diameter | 16.5 MM / 0.65 Inch |
| Discard Thickness | 26.5 MM / 1.043 Inch |
| Mounting Bolt Hole Circle Diameter | 165.1 MM / 6.5 Inch |
| California Prop 65 Warning | Prop 65 Item |
| Performance Part | Yes |
| Material | Cast Iron |
| OE/OEM Part Number | Contact for details |
| Type | Brake Disc Rotor |
| UPC | 840118337397 |
Model: Savana 3500. apf – Rotors. APF – Rotors. Slots – Designed to help clear debris and maintain a smoother braking surface. Base Extended Passenger Van 3-Door. Our support team is located in the U.S.
