Replacement Rear Right Disc Brake Rotor for 2007-2017 Lexus LS460, LS600h (AWD)
USD 104.25 USD
Conventional Or Drum-In-Hat Type Rotor: Conventional. Compatible with the following vehicles. Mounting Bolt Hole Quantity: 5. Stud/Lug Hole Quantity: 5. Harmonize Code: 8708.30.5030. Nominal Thickness: 22 MM, 0.866 IN.
Specifications
| Brand | Raybestos Brakes |
| Harmonize Code | 8708.30.5030 |
| UNSPSC Code | 25171715 |
| Overall Height | 2.596 IN, 65.95 MM |
| Outside Diameter | 335 MM, 13.189 IN |
| Nominal Thickness | 22 MM, 0.866 IN |
| Mounting Bolt Hole Diameter | 16.4 MM, 0.646 IN |
| Mounting Bolt Hole Circle Diameter | 120 MM, 4.724 IN |
| Inside Diameter | 212.7 MM, 8.374 IN |
| Discard Thickness | 20 MM, 0.787 IN |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Center Hole Diameter | 62 MM, 2.441 IN |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Diameter | 0.646 IN, 16.4 MM |
Conventional Or Drum-In-Hat Type Rotor: Conventional. Compatible with the following vehicles. Mounting Bolt Hole Quantity: 5. Stud/Lug Hole Quantity: 5. Harmonize Code: 8708.30.5030. Nominal Thickness: 22 MM, 0.866 IN.
