Wilwood SRP Drilled Performance Rotor & Hat L/H 12.01 x 1.03 - 5 x 4.75"
USD 132.33 USD
Each rotor is precision machined to less than. 001 tolerance for overall flatness, parallelism, and radial run-out on long grain carbon iron castings. The rotors are finished with a black electro coat to provide corrosion resistance.
Specifications
| Performance Part | Yes |
| Manufacturer Part Number | 160-14041-BK |
| Brand | Wilwood |
| Type | Brake Disc Rotor |
| Manufacturer Warranty | No Warranty |
| Material | Iron |
| Rotor Style | SRP Dimpled & Slotted |
| Surface Finish | Black Electro Coat |
| Width (in) | 1.03 |
| Vane Count | Vented |
| Diameter (in) | 12.01 |
| Rotor Type | SRP-BLK |
| Lug ID / Registration (in) | 2.78 |
| Far Side Inside Diameter (in) | 8.80 |
| Offset Dimension (in) | 0.590 |
| Clearance Inside Diameter (in) | 6.17 |
| Wheel Bolt Circle (in) | 5 x 4.75 |
| Face Thickness (in) | 0.25 |
| Stud Diameter (in) | 0.52 |
| Shoe Inside Dimension (in) | 7.48 |
| UPC | 889545072402 |
Each rotor is precision machined to less than. 001 tolerance for overall flatness, parallelism, and radial run-out on long grain carbon iron castings. The rotors are finished with a black electro coat to provide corrosion resistance.
